uFlamer Max
uFlamer® Max is the first standalone liquid flamer capable of producing flames up to 20 meters high. Its built-in pumping system and fuel tank make it the only plug-and-play large liquid flame unit available on the market. Equipped with an auxiliary igniter and triple high-voltage igniters, it ensures successful ignition every time.
- First standalone liquid flamer with flames up to 20m
- Built-in pump and fuel tank, plug-and-play system
- Equipped with external fuel input quick coupler
- Compact size
- Triple high voltage igniters
- Flame monitoring function
- Multiple safety configurations: cascadable power cut-off, E-stop connector, ARM indicator light, safety switch, etc.
- Durable metal tube structure
Product Specifications:
- Input and Power: 200-240VAC, 50/60 Hz, 2.5KW
- Housing Material: 304 Stainless steel
- Effect Direction: Vertical
- Max. Flame Height (No Wind): Nozzle XXH: 20m
- Fuels: ISOPAR G, H, L, M; ISOPROPANOL
- Fuel Tank Capacity: 17L
- Fuel Consumption Rate: Approximately 1L/s
- Interface: NEUTRIK POWERCON TRUE1 IN/OUT; Waterproof 3-pin and 5-pin XLR IN/OUT
- Control: DMX, 9-60V Pyro Signal
- E-stop: Yes
- ARM Indicator Light: Yes
- Liquid Level Sensor: Yes
- Ignition: High Voltage Electron Ignition * 3
- Firing Duration: 0.2-0.5s
- Use in Rain: Yes
Product Dimensions:
- Dimensions: 570 x 425 x 380mm
- Weight: 60kg
Download product manual PDF
Download product specifications PDF
